علم الفيزياء : الفيزياء الحديثة : الليزر : مواضيع عامة في الليزر :

Critical Phase-Matching

المؤلف:  Walter Koechner Michael Bass

المصدر:  Solid-state Lasers

الجزء والصفحة:  352

24-1-2021

1114

Critical Phase-Matching

The reason for not achieving the optimum second harmonic output from a particular set-up is in many cases the divergence of the pump beam. For secondharmonic generation in a negative crystal we find that Δk = 0 if no1= ne2(Θm), which is exactly true only at Θ = Θm. Shown that there is a linear relationship between small deviations δθ from the phase-matching angle and Δk. The change of Δk as a function of δθ can be large enough to limit the conversion efficiency in real devices. Consider as an example second-harmonic generation in KDP at 1.064 μm. The linear change in Δk with Θ is sufficiently great to restrict the deviation from the phase-matched direction to approximately 1.2 mrad if the coherence length is to be greater than 1 cm. Phasematching under these unfavorable conditions is termed “critical phase-matching.” Also if phase-matching is accomplished at an angle Θm other than 90 with respect to the optic axis of a uniaxial crystal, there will be double refraction.
Therefore, the direction of power flow (Poynting vector) of the fundamental and second harmonics will not be completely collinear but occur at a small angle. For a negative uniaxial crystal and type-I phase-matching, this angle is given by

........(1)

The angle has the effect of limiting the effective crystal length over which harmonic generation can take place. The beams completely separate at a distance of order
........(2)
called the aperture length where D is the beam diameter. Of course, at only a fraction of this distance the reduction of conversion efficiency because walk-off becomes noticeable and has to be taken into account. For weakly focused Gaussian beams, the aperture length can be expressed as
...... (3)
where w0 is the fundamental beam radius.
